Máquina de bobinado manual para electrodos de células cilindros.

Wechat:17720812054

Whatsapp:+86 13174506016

Email:David@batterymaking.com

  • Artículo No.:

    TMAX-JR135
  • Pago:

    L/C,T/T,Western Union, Paypal
  • Tiempo de espera:

    5 days
  • certificado:

    CE ROHS Certificate
  • Detalle del producto

Máquina de bobinado manual para electrodos de células cilindros.



modelo

Máquina de bobinado de electrodos

tensión de trabajo

AC110V / 220V, 50 / 60Hz

energía

50w

garantía

Garantía limitada de dos años con soporte de por vida.

velocidad de bobinado

0 - 170 rpm ajustable

cuchilla sinuoso

El bobinado anchos de ancho En el Ancho de de

La cuchilla sinuoso

Hoja de bobinado cuadrada personalizada según

A modelo de batería

modo de devanado

Conmutable entre relojes y

en sentido anti-horario

producción

70-100EA / H, según a a Tamaño de la batería y

Maunal

Dimensiones del producto

(L * W * H)

380 * 320 * 300mm

Peso neto

sobre 30kg

notas de aplicación

Este La máquina se puede utilizar para batería prismática

Con eje de bobinado cuadrado,

Y Usted También puede elegir el eje de bobinado redondo.

Para Bobinador de núcleo de células del cilindro,

Nosotros nosotros suministrará el bobinado adecuado

accesorios de acuerdo con a a Tu modelo de batería
